Pegard 160 - X: 9000 - Y: 650 - Z: 3000 - W: 1200 mm CNC
Informazione tecniche
- Longitudinal travel X-axis9000 mm
- Cross traverse Y-axis (table/column)650 mm (column)
- Vertical traverse Z-axis3000 mm
- Spindle traverse W-axis1200 mm
- Milling spindle taper (ISO)ISO 50
- Dia spindle -- Spindle bore160 mm
- Digital read-out (1) CNC(2)Heidenhain TNC 530
- Rotary table dimensions2 tables 2380 x 2380 mm
- Max weight on table2 tables x 30 ton
Informazioni supplementari
Type: 6055-AF16SMM
Milling, boring and turning!
Longitudinal X-travel of column: 9000 mm
Cross Y-travel of column: 650 mm
Vertical Z-travel of millinghead: 3000 mm
Horizontal W-travel of millinghead: 1200 mm
Machine can working with 6 axes simultaneous
2 hydrostatic tables CNC controlled - Weight on the table: 30 ton - Continueous 360° - Cross travel of table: 2500 mm
Toolchanger with 60 positions
- Milling head support / support de renforcement de la broche
- Drill spindle support / support portefraises
- Tipo/Modello: 160 - X: 9000 - Y: 650 - Z: 3000 - W: 1200 mm CNC
- Numero di magazzino: F.02 14162
- Categoria: [F] Foratrici e tavole girevoli
- Sottocategoria: [F.02] Foratrici a montante mobile
- Il marchio: Pegard
Numero di magazzino: F.02 14162
