Vlakslijpmachines met horizontale spil Blohm HFS 6 - X:600 - Y:300 mm

Ürün favorilere eklendi

Teknik Bilgiler

Worklength with magnetic table600 mm
Grindingwidth300 mm
Longitudinal travel X-axis (autom.)660 mm
Cross-travel Y-axis (autom.)330 mm
Travel Z-axis (autom.)275 mm
Dimensions of the table720 x 300 mm
Dimensions magnetic table 600 x 300 mm
Distance between table -- spindlecentre400 mm
Max dia grindingstone250 x 50 mm
Spindlespeeds1400 -> 2800 rpm
Motorpower4 kW
Length L -- R2600 mm
Depth Fw -- Bw2400 mm
Weight1500 kg

Ek bilgi

innerdia grindingstone: 76 mm
Tip/Model: HFS 6 - X:600 - Y:300 mm
Stok numarası: G.02 3049
Kategori: [G] Törpü makineleri
Alt kategori: [G.02] Vlakslijpmachines met horizontale spil
Marka: Blohm

Stok numarası: G.02 3049

Satılan
Satılan

ZIP formatındaki tüm fotoğrafları indirin
