Huron KX 20 X: 1200 - Y: 1000 - Z: 550 mm CNC

Ürün favorilere eklendi

» Kişisel fiyat talep edin

Teknik Bilgiler

Table longitudinal travel (X-axis)1200 mm
Cross travel head (Y-axis)1000 mm
Height travel head (Z-axis)550 mm
Table dimensions1400 x 1000 mm
Max weight on the table2 ton
Admission in spindle (ISO)HSK 63A
Power on the spindle15 kW
Control (type)Siemens Sinumerik
Toolchangeryes
Number of toolholders60 positions
Number of rotations (from X to Y rpm)10 > 15 000 rpm
Length L -- R4560 mm
Depth Fw -- Bw3955 mm
Height3132 mm
Weight12 ton

Ek bilgi

min/max distance from spindle to table: 250 > 800 mm
Tip/Model: KX 20 X: 1200 - Y: 1000 - Z: 550 mm CNC
Stok numarası: D.01 12734
Kategori: [D] Uygulama merkezi
Alt kategori: [D.01] Vertikale bewerkingscentra CNC
Marka: Huron

» Kişisel fiyat talep edin

Stok numarası: D.01 12734

İş makinasının videosunu görüntüle

Huron KX 20 X: 1200 - Y: 1000 - Z: 550 mm CNC

ZIP formatındaki tüm fotoğrafları indirin
