Berthiez Ø 4500 mm NC

Ürün favorilere eklendi

» Kişisel fiyat talep edin

Teknik Bilgiler

Chuck dia.2257 mm
Max turningdia -- passage4500 mm
Power on the spindle69 kW
Max longitudinal travel X-axis2450 mm
Max hight of workpiece Z-axis2650 mm
CommandBosch semi-automatic
Number of speeds0,8 > 125 rpm
Weight55 ton

Ek bilgi

Berthiez BM 225 sermi-automatic machine
Variable speed control for the chuck
Variable speed control for the feed
Max stroke of ram: 1000 mm
Turret can incline 45° & 30°
Max workpiece diameter: 4500 mm
Max workpiece diameter with turning to centre: 4000 mm
Max height of workpiece: 2650 mm
Max weight of workpiece: 30 ton
69 kW on chuck
Weight of machine: 40 ton
Tip/Model: Ø 4500 mm NC
Stok numarası: A.12 14099
Kategori: [A] Torna
Alt kategori: [A.12] Carrousseldraaibanken Conventioneel & CNC
Marka: Berthiez

» Kişisel fiyat talep edin

Stok numarası: A.12 14099

ZIP formatındaki tüm fotoğrafları indirin
