HL 1000 ton 4 column press

Extra info

  • 4 column hydraulic press
    high closing speed
    ideal for composite projects
    press can remain under pressure for a long period of time
    one main hydraulic single acting piston (diameter 660 mm)
    two smaller pistons to retract the stamp
    heating can used as an option (on/off)
    is installed on top of ground!
    hole in table for counterpressure (stroke 200 mm)
    Rexroth hydraulic unit 300 bar operating pressure

    Capacity 1000 ton
    Passage between uprights 1000 mm
    Max ram adjustment 800 mm
    Distance between table -- ram 1400 mm
    Table area 1200 x 1000 mm
    Electric motor (power) 55 kW
    Length 1500 mm
    Depth 1500 mm
    Height 5500 mm
    Weight 25 ton

  • Type/Model: 1000 ton 4 column press
  • Stocknummer: M.19 14018
  • Kies een Categorie: [M] Hydraulische persen
  • Subcategorie: [M.19] Koudvormpersen & Warmvormpersen
  • Merk: HL

StockNr: M.19 14018

Bekijk video werkende machine
