Geka Hydracrop SD 100 ton CNC

Produit ajouté à vos favoris

» Demandez un devis personalisé

Information technique

Capacité d'estampage110 ton
Dia x épaisseur de la tôledia 31 x 26 mm / dia 100 x 8 mm
Col de cygne610 mm
Diamètre maximaleØ 100 mm
Epaisseur max de coupe en tole600 x 15 / 400 x 20 mm
Longueur du couteau605 mm
Coupe sous 90°152 x 152 x 13 mm
Coupe sous 45°70 x 70 x 7 mm
Coupe à longueur rond /carré50 mm
Epaisseur max d'ajourage90 x 52 x 13 mm
Longueur G -- D3000 mm
Largeur Av -- Ar2000 mm
Hauteur2200 mm

Informations complémentaires

with CNC X & Y positioning table for punchstation
1 punching head
Electric backgauge for flat shear

Punching cap: 100 ton
Dia x sheet thickness: 31 x 26 mm / dia 100 x 8 mm
28 strokes/min
Depth of throat: 610 mm
Max hole dia: Ø 100 mm
Max cutting-thickness in plate: 600 x 15 mm / 400 x 20 mm
Blade length: 605 mm
90°-cut corner: 152 x 152 x 13 mm
45°-cut corner: 70 x 70 x 7 mm
Cut to length round/square: 50 mm
Max material thickness by notching: 90 x 52 x 13 mm
Power: 9 kW
Weight: 3,3 ton
Type/Modèle: 100 ton CNC
Numéro de Stock: P.13 12700
Catégorie principal: [P] Cisailles, Poinconneuses Univers., Lignes a couper a longueur et de refendage, lockformers & Lignes a scier
Subcatégorie: [P.13] Machine universelles a cisailler & poinconner
Marque: Geka Hydracrop SD
