Tornos verticales convencionales y CNC Titan Ø 3300 mm

Name: Titan Ø 3300 mm
Brand: Titan
SKU: A.12 12995

Producto agregado a sus favoritos

» Solicitar un presupuesto personalizado

Información téchnico

Chuck dia.3000 mm
Max turningdia -- passage3300 mm
Power on the spindle60 kW
Digital screenAxom Evolution 3
Number of speeds1,02 > 92 rpm
Weight48 ton

Información adicional

Tipo: SC 33 - Licencia Morando

Diámetro de la mesa: 3000 mm
Oscilación máxima: 3300 mm
Altura máxima de la pieza de trabajo: 2300 mm
Carga máxima sobre la mesa: 18 toneladas
Potencia en la mesa: 60 kW
Velocidad de la mesa: 1,02 > 92 rpm

1er SOPORTE VERTICAL
Sección del ariete: 236 x 230 mm
Movimiento vertical del soporte: 1500 mm

SOPORTE VERTICAL 2d con torreta - 5 posiciones
Movimiento vertical del soporte: 1000 mm
Tipo/Modelo: Ø 3300 mm
Numéro stock: A.12 12995
Categoría principal: [A] Tornos
Subcategoría: [A.12] Tornos verticales convencionales y CNC
Marca: Titan

» Solicitar un presupuesto personalizado

Numéro stock: A.12 12995

Descargar todas las imágenes en ZIP
